BN-202 – Molded Foam Tip Cleanroom Swab
BN-202 molded foam tip cleanroom swab with ESD‑safe polypropylene handle and sealed‑edge foam. Ultralow NVR (<0.08 mg) and ionic residues. Gamma sterilized. Perfect for hard disk drive assembly and lens cleaning.
We are committed to delivering five‑star service across every product we offer — from responsive support to reliable delivery and beyond. Your satisfaction is our benchmark.
The BN-202 molded foam tip cleanroom swab features a pure polyurethane foam head that is fully molded (not cut) to eliminate loose particles from raw foam edges. Unlike die‑cut foam swabs, the molded construction creates a smooth, sealed outer skin on all sides of the tip, drastically reducing particle generation during cleaning. The swab head is thermally fused to a black ESD‑safe polypropylene handle (surface resistivity 10⁶ – 10⁹ Ω/sq), providing static dissipation for sensitive electronic components.
The BN-202 is manufactured in a Class 10 (ISO 4) environment, then cleaned with DI water and IPA to achieve ultra‑low residue levels. The foam formulation is closed‑cell on the exterior but retains an internal micro‑porous structure for controlled liquid release.
Cleanliness & ESD data
| Parameter | BN-202 Specification |
|---|---|
| NVR (IPA) | < 0.08 mg/swab |
| Chloride (Cl⁻) | < 0.15 µg/swab |
| Sodium (Na⁺) | < 0.12 µg/swab |
| Particles (≥0.3 µm) | < 5,000/swab |
| Surface resistivity (handle) | 10⁶ – 10⁹ Ω/sq |
| Foam hardness (Shore 00) | 40 ± 5 |
Dimensions
| Feature | Measurement |
|---|---|
| Head shape | Rectangular (molded) |
| Head width | 9.5 mm (0.374″) |
| Head thickness | 6.0 mm (0.236″) |
| Head length | 19.0 mm (0.748″) |
| Handle length | 115 mm (4.528″) |
| Total length | 134 mm (5.276″) |
Sterilization & packaging
Sterilization: Gamma, SAL 10⁻⁶
Packaging: Individually sealed in cleanroom peel‑pouch; 100 swabs/pouch, 5 pouches/case (500 swabs/case)
Shelf life: 3 years
Typical applications
Hard disk drive (HDD) slider and ramp cleaning
Photomask and reticle edge cleaning
Precision lens and mirror cleaning (no scratches)
Static‑sensitive PCB and connector cleaning
The BN-202’s molded foam tip provides superior edge integrity compared to cut foam swabs, making it the preferred choice for applications where loose particles cannot be tolerated. Each lot includes an ESD verification report and ionic contamination analysis.
