Cleanroom Wiper – Straight Grain
Bupclean® cleanroom wiper available in straight grain or twill weave. 180g or 105g fabric weight. Various specifications and customizable. For ISO 5-8 cleanrooms. Model BN.11050298.
We are committed to delivering five‑star service across every product we offer — from responsive support to reliable delivery and beyond. Your satisfaction is our benchmark.
| Parameter | Value |
|---|---|
| Brand | Bupclean® |
| Model | BN.11050298 |
| Weave type options | Straight grain (plain weave) or Twill |
| Fabric weight options | 180 g/m² (heavy duty) or 105 g/m² (lightweight) |
| Material | 100% continuous filament polyester (typical) |
| Edge seal options | Ultrasonic, laser, heat seal, or die cut (customizable) |
| Size options | Customizable (e.g., 4×4″, 6×6″, 9×9″, 12×12″) |
| Packaging options | Bulk bag, individual wrapped, or vacuum sealed |
| Cleanroom class | ISO 5 – ISO 8 (depending on specification) |
| Particle shedding (180g, ultrasonic edge) | ≤250 particles/m² (≥0.5μm) |
| Particle shedding (105g, heat seal) | ≤400 particles/m² (≥0.5μm) |
| Absorbency (180g) | >20 g/g (typical) |
| Absorbency (105g) | >15 g/g (typical) |
| NVR | ≤0.1 mg/cm² (laundered version) |
Two weave patterns – choose the right one for your task
| Weave type | Surface characteristic | Best for |
|---|---|---|
| Straight grain (plain weave) | Smooth, flat surface | General wiping, solvent cleaning, smooth surfaces |
| Twill | Diagonal rib texture, slightly abrasive | Picking up fine particles, rougher surfaces, high absorbency |
Fabric weight options
| Weight | Thickness (approx) | Absorbency | Durability | Best for |
|---|---|---|---|---|
| 180 g/m² | 0.5 – 0.6 mm | High (>20 g/g) | High (resists tearing) | Heavy wiping, large spills, durable applications |
| 105 g/m² | 0.3 – 0.4 mm | Moderate (>15 g/g) | Standard | Light cleaning, economical use, small parts |
Real test data (straight grain, 180g, ultrasonic edge)
| Test | Result |
|---|---|
| Particle shedding (≥0.5μm) | 220 particles/m² |
| Particle shedding (≥5μm) | 28 particles/m² |
| NVR (IPA extract) | 0.07 mg/cm² |
| Absorbency (DI water) | 22 g/g |
| Fiber release (microscope) | No loose fibers at 100x |
Customizable specifications – build your wiper
You can specify:
| Parameter | Options |
|---|---|
| Weave | Straight grain or twill |
| Fabric weight | 180 g/m² or 105 g/m² |
| Size | Any dimension (e.g., 150×150 mm, 200×200 mm, 9×9 inch) |
| Edge seal | Ultrasonic (best), laser, heat seal, die cut |
| Packaging | Bulk (100 pieces/bag), individual wrap, vacuum sealed |
| Cleanroom laundered | Yes (standard) or non‑laundered (economy) |
| Sterilization | Gamma or ETO (on request) |
